Specifications
Specifications
Wireless Specifications
Communications
RF433
Communication frequency
433-440MHz
Transmission range
≤100M(In empty area 100M )
Data rate
10Kbps
Memory
100,000@13Byte barcode
Battery capacity
2000mAh (Lithium battery)
Dimensions
70mm*95mm*168mm(L*W*H)
Weight
172g
Receiver
188g
Charging time
6H
The working time of the full charge
6h(continuous reading situation)
12h(Manual reading situation)
More than 15 days(Stand-by time)
Operation mode
Read-time mode/ Inventory mode/Cache mode
ENVIRONMENTAL
Ambient Light
fluorescent light 4000 lx max , direct sun light 80,000 lx max ,white light 4000 lx max
Operating Temperature
-20°C to 65°C / -4°F to 149°F
Storage Temperature
-30° to 70°C /-22° to 158°F(storage)
Humidity
5%-90%
Shock Drop Test
1.5m drop onto concrete surface
ELECTRICAL
Interface
RS-232/USB HID KEYBOARD/USB VCP
Voltage Requirement
5V±10%
Current Consumption
Max:138mA
OPTICAL CHARACTERISTICS
Photo Sensor
CCD linear sensor
Sensor Resolution
2500 pix
Light Source
632nm Red LED
SCANNING PERFORMANCE
Scan Rate
350+50(scans/second)
Decode Angle
Pitch angle: ±30°
Skew angle: ±75°
Tilt angle: ±45°
Print Contrast
〉25%UPC/EAN 13(13mil)
Min.Resolution
0.101mm/4mil(PCS 0.9)
Curvature
R≥15 mm (EAN8),R≥20 mm (EAN13) (resolution=0.26mm,PCS=0.9)
Language
Multiple languages
Error rate
1/500W
SUPPORTED BARCODE SYMBOLOGIES
EAN13, EAN18, UPC A, UPC E, CODEABAR(NW-7), CODE 39, CODE 93, INTERLEAVED 2OF5, STANDARD 2OF5, MATRIX 2OF5, CODE 128, CODE 11, CHINESE POST.
