Specifications
PHYSICAL CHARACTERISTICS
Dimensions
30 mm x 26 mm x 12 mm（1.18 in x 1.02 in x .47 in）
Weight
8g (0.28 oz)
Configurations
Decode
ENVIRONMENTAL
Ambient Light
Fluorescent light 4000 lx max , direct sun light 80,000 lx max ,white light 4000 lx max
Operating Temperature
-0°to 65°C / 32°to 149°F
Storage Temperature
-30°to 70°C /-22°to 158°F
Humidity
5 - 90% (operation) ) 5 - 90% (storage)
Shock drop test
1.2m drop onto concrete surface
ELECTRICAL
Interface
TTL-232/USB
Interface connector
0.5-12P FPC
Voltage requirement
DC 5V±10%
Current consumption
Max:120mA
OPTICAL CHARACTERISTICS
Photo sensor
CCD linear sensor
Sensor Resolution
2500pix
light source
632nm red led
SCANNER PERFORMANCE
Scan Rate
350±50 (scans/second)
Scan Angle
Pitch angle:±30°
Skew angle:±70°
Tilt angle:±45°
Min X Dimension
0.101mm/4mil（PCS 0.9）
Print Contrast
〉25%UPC/EAN 13（13mil）
Curvature
R≥15 mm (EAN8)，R≥20 mm (EAN13) （resolution=0.26mm，PCS=0.9）
SUPPORTED BARCODE SYMBOLOGIES
EAN13，EAN8，UPC A，UPC E，CODABAR（NW-7），CODE 39，CODE 93，INTERLEAVED 2OF5，STANDARD 2OF5，MATRIX 2OF5，CODE 128，EAN/UCC 128，CODE 11，CHINESE POST
