Specification
Specifications
PHYSICAL CHARACTERISTICS
Dimensions
68mm H x 48 mm W x 24 mm D
Weight
USB/USB VCP：118g
RS-232:147g
ENVIRONMENTAL
Ambient Light
fluorescent light 10,000 lx max , direct sun light 100,000 lx max ,white light 10,000 lx max
Operating Temperature
-30 to 60 °C / -22 to 140 °F
Storage Temperature
-40 to 70 °C / -40 to 158 °F
Humidity
5%-90%
Shock Drop Test
1.2m drop onto concrete surface
ELECTRICAL
Interface
RS-232/USB HID KEYBOARD/USB VCP
Voltage Requirement
5V±10%
Current Consumption
Max:280mA
OPTICAL CHARACTERISTICS
Photo Sensor
CMOS array sensor
Sensor Resolution
648X488 pixels
Aim Light Source
Red Bar LED
Light Source
White LED
SCANNING PERFORMANCE
Scan Rate
Up to 60fps
Scan Angle
Pitch angle: ±65°
Skew angle: ±60°
Tilt Angle: ±180°
Min resolution
1D: 5mil(0.127mm）
Print Contrast
〉25%UPC/EAN 13(13mil)）
Field of View
34°(H) x 26°(V)
SUPPORTED BARCODE SYMBOLOGIES
1D：UPC/EAN,Code 128, Code 39, Code 93, Code 11, Matrix 2 of 5, Interleaved 2 of 5, Codabar, MSI，GS1 Databar
2D：QR, PDF417，Data Matrix
