Specifications
Specifications
PHYSICAL CHARACTERISTICS
Dimension (L*W*H)
90mm*67mm*168mm(L*W*H)
Weight
120g
ENVIRONMENTAL
Temp
0°- 50°C(operation) ， -10°- 60°C (storage)
Humidity
20 - 85% (operation),20 - 95% (storage)
Shock drop test
1.5m drop onto concrete surface
Ambient light
0-80，000lx
ELECTRICAL
Interface
RS-232/USB HID KEYBOARD/USB VCP
Voltage requirement
DC5V±10%
Current consumption
Max:240mA
OPTICAL CHARACTERISTICS
Photo sensor
CMOS linear sensor
Sensor resolution
640x480 pixels
Light source
White LED*1
Aim light source
Red Bar LED
SCANNING PERFORMANCE
Decode angle
Pitch angle:±60°
Skew angle:±60°
Tilt angle:±180°
Min resolution
1D：0.101mm/4mil（PCS 0.9）
2D：0.178mm/7mil（PCS 0.9）
Min.PCS value
>20%UPC/EAN 13（13mil）
Language
Multiple languages
Field of View
46°(H),35°(V)
SUPPORTED BARCODE SYMBOLOGIES
1D：Codabar,Code128,Code11,Code32,Code39,Code93,Composite,EAN/UPC,EAN-8,EAN-13,GS1 DataBar Expanded,GS1 DataBar Limited,GS1 DataBar Omnidirectional,Hong Kong 2 of 5(China Post),Interleaved 2 of 5,Matrix 2 of 5,Pharmacode.RSS-14,RSS-LIMITED,RSS-EXPANDED,Industrial 2 of 5,Telepen,Trioptic Code, UPC-A,UPC-E
2D：Maxicode,MicroPDF417,Micro QR Code,MSI,PDF417,QR Code, DataMatrix
