Name: Winson Low Price 2D COMS POS Barcode Scanner QR Code Barcode Reader USB/RS232
Brand: Winsonchina
SKU: WNI-6801g
Availability: InStock
Rating: 5 (1 reviews)

Home > Handheld Barcode Scanner > Wired Handheld Barcode Scanner > CMOS

Winson Low Price 2D COMS POS Barcode Scanner QR Code Barcode Reader USB/RS232

Description Specifications Review

Description

Winson Low Price 2D COMS POS Barcode Scanner QR Code Barcode Reader USB/RS232

Highlights

♦ Superior decoding performance
640x480 million pixel professional lens ensure quick barcode scanning.
30% faster than ordinary scanner.
♦ Support read small high-density barcode
It quickly reads paper and screen codes of different sizes, densities and digits.(1000-digit passenger code, 2000-digit paper code can be read)
♦ Long life span
Shockproof and Anti-broken
Winson WNI-6801g barcode scanner, after 1.2 drop onto concrete surface floor, still works well.
Famous brand C&k button
Winson barcode scanner uses world famous brand C&k trigger button, even after 1500，000 times trigger, it still works normally.

Product Details

► Winson barcode scanners are compatible with almost all common systems, as Windows, Android, Mac OS, IOS, Linux etc.
► Winson barcode scanners support multiple keyboard language: USA, Germany, French, Italy, Spanish, Turkey, Belgium, Brazil Czech and so on.
► Support Custom Function: such as add a prefix/suffix, delete the last four characters, interlaced upload data.
► Support self-upgrade, no limitation for Keyboard Cash.
► 32 Bite CPU, highly efficient, and greatly improves the working efficiency.
► Winson barcode scanners are play and pluy, no need to manual install driver .
► Can be adjusted the working mode of barcode scanner according to your own needs, as continuous reading or single reading, scan the same barcode or not, delay the time to upload data or not.
► Winson barcode scanners apply to registry office of the airport/train station, hospitals, warehouses, supermarkets, retail stores, libraries, catering, logistics, express delivery, etc.
► Support multi-barcodes, such as: 1D： UPC/EAN, UPC/EAN with supplementals, Bookland EAN, ISSN, UCC Coupon Extended Code, Code 128, GS1-128, ISBT 128, Code 39, Code 39 Full ASCII, Trioptic Code 39, Code 32, Code 93, Code 11, Matrix 2 of 5, Interleaved 2 of 5, Discrete 2 of 5, Codabar, MSI, Chinese 2 of 5, GS1 DataBar variants, Korean 3 of 5, ISBT Concat
2D：PDF417, MicroPDF417, Composite Codes, TLC-39, Data Matrix, Maxicode, QR Code, MicroQR, Aztec

Click Here to Contact us »

Specifications

Specifications

PHYSICAL CHARACTERISTICS

Dimension (L*W*H)
90mm*67mm*168mm(L*W*H)
Weight
120g

ENVIRONMENTAL

Temp
-20°- 60°C(operation) ， -40°- 80°C (storage)
Humidity
5 - 95% (operation),20 - 95% (storage)
Shock drop test
1.5m drop onto concrete surface
Ambient light
0-80，000lx

ELECTRICAL

Interface
RS-232/USB HID KEYBOARD/USB VCP
Voltage requirement
DC5V±10%
Current consumption
Max:150mA

OPTICAL CHARACTERISTICS

Photo sensor
CMOS linear sensor
Sensor resolution
640x480 pixels
Light source
White LED*1
Aim light source
Red Bar LED

SCANNING PERFORMANCE

Decode angle
Pitch angle:+550°
Skew angle:+360°
Tilt angle:+55°
Min resolution
1D：0.101mm/4mil（PCS 0.9）
2D：0.178mm/7mil（PCS 0.9）
Min.PCS value
>20%UPC/EAN 13（13mil）
Language
Multiple languages
Field of View
36°(H),27°(V)

SUPPORTED BARCODE SYMBOLOGIES

1D：Code 128,Ean-13 ,Ean-8,UPC-E,UPC-A,ITF-25(Interleaved 2 0f 5),Code39,Code93,Codabar
2D：PDF417,QR Code, DataMatrix
