Wireless Characteristics |
|||||||
|
Communication mode |
Cache mode/Inventory mode |
||||||
|
Communication mode |
2.402 to 2.480GHz |
||||||
|
Transmission range |
30m(In empty area) |
||||||
|
Battery capacity |
2000mAh (Lithium battery) |
||||||
|
Charge Time from Empty to Full Charge |
5H |
||||||
|
Duration of use |
11H (wireless mode,real-time mode communication mode,60 scans/minute) |
||||||
|
Electrical Characteristics |
|||||||
|
Interface Supported |
USB HID KEYBOARD/USB VCP |
||||||
|
Input Voltage |
DC 5V±5% |
||||||
|
Current |
Max:185mA |
||||||
|
Performance Characteristics |
|||||||
|
Light Source |
650nm visible laser diode |
||||||
|
Decoding speed |
100±20/s |
||||||
|
Scanning Angle |
Pitch angle:-30° to 0°,0° to +30° |
||||||
|
|
Skew angle:-60° to 0°,0° to +60° |
||||||
|
|
Tilt angle:-30° to 0°,0° to +30° |
||||||
|
Min Resolution |
1D : 4mils |
||||||
|
Min .PCS value |
>30%UPC/EAN 13(13mil) |
||||||
|
Decode Capability |
1D:EAN13,EAN8,UPC A,UPC E,ISSN, ISBN, UPC-A , UPC-E , CODE39 , CODE32, CODE128, UCC-EAN128, CODE93, CODE11,CODABAR, MSI, CROSS 25 CODE, CHINA POST 25 CODE, MATRIX25CODE,INDUSTRIAL 25 CODE, GS1 DataBar Omnidirectional, GS1 DataBar Limited |
||||||
|
Environmental Characteristics |
|||||||
|
Temperature |
operation:0°C-50°C |
||||||
|
|
storage:-10°C-60°C |
||||||
|
Humidity |
operation:20%~85% (no condensation) |
||||||
|
|
storage:20%~95%(no condensation) |
||||||
|
Physical Characteristics |
|||||||
|
Dimensions |
90mm x67mm x 168mm(L*W*H) |
||||||
|
Weight |
130g |
||||||
|
Indicator |
Beeper, LED |
||||||
|
Decoding Depth of Field |
|||||||
|
Symbology |
Resolution |
Barcode number |
Barcode width |
Nearest |
Farthest |
||
|
Code128 |
5mil |
20 |
4.3x1.5cm |
5cm |
10cm |
||
|
Code128 |
15mil |
7 |
4.3x1.5cm |
2.5cm |
26cm |
||
|
Code39 |
6.67mil |
16 |
4.4x1.5cm |
3cm |
19cm |
||
|
Code39 |
20mil |
4 |
4.3x1.5cm |
3cm |
32cm |
||
|
EAN13 |
13.34mil |
13 |
4.2x1.5cm |
2cm |
24cm |
||
