| CPU | Quad-core 1.3 GHz |
| Operating System | Android 6.0 |
| Memory(ROM+RAM) | 16 GB +2 GB |
| Expansion Slot | Micro SD card, up to 32 GB |
| Display | 4.7-inch, 1280 x 720 high resolution |
| Touch Panel | Industrial-grade capacitive touch panel (supporting operation with gloves) |
| Camera (optional) | 8 MP autofocus camera in the back side, autofocus lens, LED flash |
| Exit Window | Corningâ Gorillaâ glass |
| Keypad | 4 front keys, 4 side keys, Power key (can be set as customized key) |
| Battery | 3.8V 3600mAh / 3.7V 3300mAh lithium polymer battery(PDA) + 3.7V 5200 mAh(pistol grip) |
| Audio | Built-in microphone /Micro USB/Headphone connector |
| Notification | Vibrator alerts/LED/Audio notification |
| Vibration Motor | Built-in programmable vibration motor |
| Sensor | G-Sensor/Proximity sensor/Light sensor |
| Dimensions (LxWxD) | PDA: 150 mm x 73.5 mm x 16 mm（head 24mm thick） PDA + handle：175mm x 89mm x 165mm |
| Weight | PDA（include battery）+ pistol grip（with RFID）710g PDA（include battery）+ pistol grip（without RFID）530g |
| Wireless WAN (Network frequency) |
Asia & Europe 2G: B2/B3/B5/B8 3G: WCDMA：B1/B2/B5/B8, CDMA&EVDO：BC0, TD-SCDMA：B34/B39 4G: FDD-LTE：B1/B3/B7/B8/B20, TDD-LTE：B38/B39/B40/B41 America 2G: B2/B3/B5/B8 3G: B2/B5 4G: B2/B4/B5/B17 |
| Wireless WAN (Data service) |
GSM/GPRS/EDGE/CDMA/UMTS/HSPA/HSPA+/EVDO/WCDMA/TD-SCDMA/TDD-LTE/FDD-LTE |
| Wireless LAN | Wi-Fi 802.11a/b/g/n (Dual-band Wi-Fi: 2.4G+5G) |
| Bluetooth | Bluetooth 4.0 |
| GPS | GPS/AGPS/BEIDOU/GLONASS |
| Development Tools | Android SDK+JDK+Eclipse |
| Programming Language | Java |
| Operating Temp. | -20℃ ~ 60℃ （-4℉ ~140℉） |
| Storage Temp. | -40℃ ~ 60℃（-40℉ ~140℉ ）battery included -40℃ ~ 70℃（-40℉ ~158℉）battery not included |
| Relative Humidity | 0 ～ 95% （No condensation） |
| Sealing | IP65 |
| Electrostatic Discharge | ±15 kV air discharge, ±8 kV direct discharge |
| Scan Precision | 5mil |
| Rotate Angle | ±35° |
| Pitch Angle | ±65° |
| Skew Tolerance | ±50° |
| Ambient Light | Sunlight: 10,000ft. Candles (107,640Lux) Artificial: 450ft. Candles (4,844Lux) |
| Scan Frequency | 104±12 times/second |
| Laser Safety Grade | Class II |
| Code Support | UPC/EAN, POST, Code 128, Code 39, Code 93, Code 11, Coda bar, Interleaved 2 of 5, Discrete 2 of 5, Chinese 2 of 5, MSI, RSSI etc. |
| Scan Precision | 3mil c39/128 |
| Rotate Angle | 360° |
| Pitch Angle | ±45° |
| Skew Tolerance | ±65° |
| Scan Frequency | 50ms |
| Laser Safety Grade | Class II |
| Image Resolution | 844(H)×640(V) |
| Image Frame | 60fps |
| Light Source System | White light, laser aiming |
| Minimum Printing Contrast |
20% |
| Code Support | Aztec Code , Codabar , Codablock F , Code 11 , Code 128 , Code 2 of 5 , Code 39 , Code 93 , Data Matrix , EAN/JAN-13 , EAN/JAN 8 , EAN-UCC Composite Codes , EAN-UCC Emulation , IATA Code 2 of 5 , Interleaved 2 of 5 , Matrix 2 of 5 , MaxiCode , MicroPDF417 , MSI , PDF417 , Postal Codes ( Australian Post , British Post , Canadian Post , China Post , Japanese Post , Korea Post , Netherlands Post , Planet Code , Postnet ) , Plessey Code , PosiCode , QR Code , RSS Expanded , RSS Limited , RSS-14 , TCIF Linked Code 39 , Telepen , Trioptic Code , UPC-A , UPC-E etc |
| Frequency | 902MHz-928MHz，865MHz-868MHz（Customize according to required band） |
| Protocol | ISO18000-6B/6C/6D（According to required band） |
| Antenna | 4dBi circularly polarized antenna |
|
