Highlights
♦ Easy to use and durable
1.Using android 6.0 operating system,strong compatibility,fully improved running speed,the newly designed UI interface is more user-friendly;
2.4core 1.3 GHz high-performance processor,16GB ROM+2GB RAM,running speed faster;
3.High-sensitivity industrial-grade capacitive touch screen,smooth operation;
4.IP65 degree of protection,completely dustproof prevent water invasion,it can be used with confidence even in dusty or rainy environments.
♦ Long range,wide angle,multi-mode data collection
1.Support long-distance read/write 902-928 MHz UHF RFID data，read/write specific tags distance up to 3m，suitable for mobile applications that need to collect data at high or long distances;wide read/write angle ,range up to 90°，data collection faster,users do no need to find the reading angle, can saves more working time;
2.Optional 1D/2D barcode, GPS positioning, camera and other data collection methods,fully meet the user's on-site data collection needs.
♦ Multiple wireless communications
1.Support multiple wireless communication methods such as wireless wide area network WCDMA/GPRS/GSM;
2.Support Wi-Fi wireless LAN transmission;
3.Support Bluetooth 4.0+LE close range data transmission;
4.Support high-performance GPS/AGPS/Beidou/GLONASS navigation chip, more accurate positioning.
♦ Ultra-lightweight
1.Sophisticated design,small and portable,with battery is only 383g,the lightest of its kind;
2.Ergonomic design,consistent with peoples handheld habits,continuous use for a long time without fatigue, work is very relaxed.
♦ Long battery life
1.Equipped with large capacity 3.7V 6000 mAh lithium polymer safety battery,provide stable and reliable power supply for users to work continuously for a long time；
2.Support fast charging, greatly reduce charging time, work more efficiently.
Specifications
System configuration
| CPU |
Quad-core 1.3 GHz |
| Operating System |
Android 6.0 |
| Memory(ROM+RAM) |
16 GB +2 GB |
| Expansion Slot |
Micro SD card |
| Display |
3.5-inch,960X640 high resolution |
| Touch Panel |
Industrial-grade capacitive touch panel |
| Camera (optional) |
8 MP autofocus camera in the back side, autofocus lens, LED flash |
| Exit Window |
Corningâ Gorillaâ glass |
| Keypad |
Anti-wear, internal light-transmitting industrial keyboard |
| Battery |
3.7V 6000 mAh |
| Audio |
Built-in microphone |
| Notification |
Vibrator alerts/LED/Audio notification |
| Vibration Motor |
Built-in programmable vibration motor |
| Sensor |
G-Sensor |
Structural parameter
| Dimensions (LxWxD) |
189 mm x 70 mm x 43.5 mm |
| Weight |
383G(include battery) |
Communication Transmission
Wireless WAN
(Network frequency) |
2G：B2/B3/B5/B8
3G：WCDMA：B1
CDMA&EVDO：BC0
TD-SCDMA：B34/B39
4G：FDD-LTE：B1/B3/B5
TDD-LTE：B38/B39/B40/B41 |
Wireless WAN
(Data service) |
GSM/GPRS/EDGE/CDMA/UMTS/HSPA/HSPA+/EVDO/WCDMA/TD-SCDMA/TDD-LTE/FDD-LTE |
| Wireless LAN |
Wi-Fi 802.11 a/b/g/n |
| Bluetooth |
Bluetooth 4.0+LE |
| GPS |
GPS/AGPS/北斗/GLONASS |
Operating environment
| Development Tools |
Android SDK + JDK + Eclipse |
| Programming Language |
Java，C |
| Operating Temp. |
-20℃ ~ 60℃ |
| Storage Temp. |
-40℃ ~ 60℃（battery included）
-40℃ ~ 70℃（battery not included） |
| Relative Humidity |
0 ～ 95% (No condensation) |
| Sealing |
IP65 |
1D Laser Scanner
| Scan Precision |
³ 4 mil |
| Scan depth of field |
3.81 cm – 60.98 cm |
| Scan Angle |
47°±3°（standard） |
| Scan speed |
102 times/s ± 12 times （bidirectional） |
1D / 2D Area Imager
| Optical resolution |
³ 3 mil |
| Scan Angle |
Omnidirectional |
| Scan speed |
300 times/s |
| Code Support |
Aztec Code , Codabar , Codablock F , Code 11 , Code 128 , Code 2 of 5 , Code 39 , Code 93 , Data Matrix , EAN/JAN-13 , EAN/JAN 8 , EAN-UCC Composite Codes , EAN-UCC Emulation , IATA Code 2 of 5 , Interleaved 2 of 5 , Matrix 2 of 5 , MaxiCode , MicroPDF417 , MSI , PDF417 , Postal Codes ( Australian Post , British Post , Canadian Post , China Post , Japanese Post , Korea Post , Netherlands Post , Planet Code , Postnet ) , Plessey Code , PosiCode , QR Code , RSS Expanded , RSS Limited , RSS-14 , TCIF，Linked Code 39 , Telepen , Trioptic Code , UPC-A , UPC-E 等 |
RFID(UHF)
| Frequency |
902MHz-928MHz |
| Protocol |
ISO18000-6C(EPC C1G2) |
| Antenna |
2dBi circularly polarized antenna |
| Output power |
<1 W (30 dBm) |
| Read distance |
Within 2.5 m (specific label up to 3 m) |
| Write distance |
Within 0.8 m |
Input/output Ports
| USB Port |
1 （Micro USB port） |
| Charger Port |
1 (Bottom charging interface) |
| OTG |
Support |
Accessories
| Standard |
Battery, Power adapter,Strap, Hand rope |
| Optional |
Bottom charging card holder, USB data cable, protective film |
