Specifications
Specifications
PHYSICAL CHARACTERISTICS
Dimensions
65mm x 61.2mm x 35.5mm
Weight
28.7g
Configurations
Decode
ENVIRONMENTAL
Ambient Light
Fluorescent light 1600 Lux max, direct sun light 80,000 lx max
Operating Temperature
0° to 50°C
Storage Temperature
-5°C to 55°C
Humidity
5 - 95% (operation) 5 - 95% (storage)
Shock drop test
1.2m drop onto concrete surface
ELECTRICAL
Interface
TTL-232/USB/RS-232/RS-485
Interface connector
0.5-12P FPC
Voltage requirement
DC 5V±5%(/USB/RS-232/RS-485)
DC 3.3V±5%(TTL-232)
Current consumption
Max:135mA
Min:74mA
OPTICAL CHARACTERISTICS
Photo sensor
CMOS array sensor
Sensor Resolution
1280X800 pixels
Aim light source
Red Bar LED
Light source
Green LED*4
SUPPORTED BARCODE SYMBOLOGIES
1D:UPC/EAN,Code 128, Code 39, Code 93, Code 11, Matrix 2 of 5, Interleaved 2 of 5, Codabar, MSI,GS1 Databar
2D:QR,PDF417,Data Matrix
