Specifications
Specifications
Wireless Specifications
Communications mode
Wired transmission mode/ Wireless Read-time mode/Inventory mode／Cache mode
Communication frequency
433-440MHz
Transmission range
≤100M（In empty area 100M ）
Data rate
10Kbps
Memory
100，000@13Byte barcode
Battery capacity
1500mAh (Lithium battery)
Dimensions
Scanner: 90mm*67mm*168mm(L*W*H) Receiver: 55mm*24mm*8mm(L*W*H)
Weight
160g
Receiver
5g
Charging time
4.5H
The working time of the full charge
6h（continuous reading situation）
12h（Manual reading situation）
More than 15 days（Stand-by time）
Operation mode
Read-time mode/ Inventory mode/Cache mode
ENVIRONMENTAL
Ambient Light
fluorescent light 4000 lx max , direct sun light 80,000 lx max ,white light 4000 lx max
Operating Temperature
0°C to 50°C / 32°F to 122°F
Storage Temperature
-10° to 60°C / 14° to 140°F(storage)
Humidity
20%-85%
Shock Drop Test
1.5m drop onto concrete surface
ELECTRICAL
Interface
USB HID KEYBOARD/USB VCP
Voltage Requirement
5V±10%
Current Consumption
Max:135mA
OPTICAL CHARACTERISTICS
Photo Sensor
CCD linear sensor
Sensor Resolution
2500 pix
Light Source
632nm Red LED
SCANNING PERFORMANCE
Scan Rate
350+20(scans/second)
Decode Angle
Pitch angle: ±35°
Skew angle: ±75°
Tilt angle: ±40°
Print Contrast
〉25%UPC/EAN 13（13mil）
Min.Resolution
0.115/4.5mil (PCS 0.9)
Curvature
R≥15 mm (EAN8)，R≥20 mm (EAN13) （resolution=0.26mm，PCS=0.9）
Language
Multiple languages
Error rate
1/500W
SUPPORTED BARCODE SYMBOLOGIES
EAN13, EAN18, UPC A, UPC E, CODEABAR(NW-7), CODE 39, CODE 93, INTERLEAVED 2OF5, STANDARD 2OF5, MATRIX 2OF5, CODE 128, CODE 11, CHINESE POST.
