Specification
Specifications
PHYSICAL CHARACTERISTICS
Dimensions（L x W x H）
70 mm×95mm×168mm
Weight
175g（6.08oz）
ENVIRONMENTAL
Temp
-20°-65°C / -4°to 149°F (operation)
-30°- 70°C /-22°to 158°F(storage)
Humidity
5 - 90% (operation) ) 5 - 90% (storage)
Ambient light
Fluorescent light 4,000 lx max , direct sun light 80,000 lx max ,white light 4,000 lx max
Shock drop test
1.5m drop onto concrete surface
ELECTRICAL
Interface
RS-232/USB HID KEYBOARD/USB VCP
Voltage requirement
DC5V±10%
Current consumption
Max :138 mA
OPTICAL CHARACTERISTICS
Photo sensor
CCD linear sensor
Sensor resolution
2500Pix
Light source
632nm red LED
SCANNING PERFORMANCE
Scan rate
350±50 (scans/second)
Decode angle
Pitch angle：±70°
Skew angle：±85°
Tilt angle：±45°
Min resolution
0.101mm/4mil（PCS 0.9）
Min.PCS value
>25%UPC/EAN 13（13mil）
Curvature
R≥15 mm (EAN8)，R≥20 mm (EAN13) （resolution=0.26mm，PCS=0.9）
Language
Multiple languages
Error rate
1/500W
SUPPORTED BARCODE SYMBOLOGIES
EAN-13, EAN-8, UPC-A, UPC-E, ISSN,ISBN, Codabar, Code 128, Code 93, ITF-6,ITF-14, Interleaved 2 of 5, Industrial 2 of 5,Standard 2 of 5, Matrix 2 of 5, GS1 Databar,Code 39, Code 11, MSI-Plessey, Plessey
