Specifications
Specifications
PHYSICAL CHARACTERISTICS
Dimension (L*W*H)
95mm*70mm*168mm(L*W*H)
Weight
127.8g
ENVIRONMENTAL
Temp
-20° to 60°C / -4° to 140°F(operation)
-40°-to 80°C /-40° to 176°F(storage)
Humidity
5 - 95% (operation) 5 - 95% (storage)
Shock drop test
1.2m drop onto concrete surface
Ambient light
Fluorescent light 4,000 lx max, direct sun light 80,000 lx max, white light 4,000 lx max
ELECTRICAL
Interface
RS-232/USB HID KEYBOARD/USB VCP
Voltage requirement
5VDC±10%
Current consumption
Max:120mA
OPTICAL CHARACTERISTICS
Photo sensor
CMOS array sensor
Sensor resolution
648X488 pixels
Light source
White LED*1
Aim light source
Red Bar LED
SCANNING PERFORMANCE
Decode angle
Pitch angle:±65°
Skew angle:±60°
Tilt angle:±180°
Min resolution
1D:5mil(0.127mm)
Min.PCS value
>30%UPC/EAN 13(13mil)
Language
Multiple languages
Field of View
34°(H),26°(V)
SUPPORTED BARCODE SYMBOLOGIES
1D：UPC/EAN,Code 128, Code 39, Code 93, Code 11, Matrix 2 of 5, Interleaved 2 of 5, Codabar, MSI，GS1 Databar
2D：QR, PDF417，Data Matrix
