Specifications
Specifications
PHYSICAL CHARACTERISTICS
Dimensions
70 mm H x95 mm W x168 mm(L*W*H）
Weight
130g
ENVIRONMENTAL
Ambient Light
fluorescent light 4000 lx max , direct sun light 80,000 lx max ,white light 4000 lx max
Operating Temperature
-20°C to 60°C / -4°F to 140°F
Storage Temperature
-40°C to 80°C /-40°F to 176°F
Humidity
5%-90%
Shock Drop Test
1.5m drop onto concrete surface
ELECTRICAL
Interface
USB HID KEYBOARD/USB VCP
Voltage Requirement
5VDC±10%
Current Consumption
Max:120mA
OPTICAL CHARACTERISTICS
Photo Sensor
CMOS array sensor
Sensor Resolution
640X480 pixels
Aim Light Source
Red Bar LED
Light Source
white LED*1
SCANNING PERFORMANCE
Scan Rate
Up to 30fps
Scan Angle
Pitch angle: ±65°
Skew angle: ±60°
Tilt angle: ±180°
Min X Dimension
1D:5mil(0.127mm)
Print Contrast
〉25%UPC/EAN 13（13mil）
Field of View
34°(H),26°(V)
SUPPORTED BARCODE SYMBOLOGIES
1D: UPC/EAN,Code 128, Code 39,
Code 93, Code 11, Matrix 2 of 5, Interleaved 2 of 5, Codabar, MSI
2D: QR, PDF417, Datametrix
