Specifications
Specifications
PHYSICAL CHARACTERISTICS
Dimension (L*W*H)
90mm*67mm*168mm(L*W*H)
Weight
120g
ENVIRONMENTAL
Temp
0° to 40°C / 32° to 104°F(operation)
-40° to 70°C /-40° to 158°F(storage)
Humidity
5 - 90% (operation) ) 5 - 90% (storage)
Shock drop test
1.5m drop onto concrete surface
Ambient light
Fluorescent light 4,000 lx max, direct sun light 80,000 lx max, white light 4,000 lx max
ELECTRICAL
Interface
RS-232/USB HID KEYBOARD/USB VCP
Voltage requirement
5V±10%
Current consumption
Max:380mA
OPTICAL CHARACTERISTICS
Photo sensor
CMOS array sensor
Sensor resolution
640X480 pixels
Light source
White LED*1
Aim light source
Red Bar LED
SCANNING PERFORMANCE
Decode angle
Pitch angle:±65°
Skew angle:±60°
Tilt angle:±180°
Min resolution
1D:4mil(0.101mm)
2D:8mil(0.202mm)
Min.PCS value
〉20%UPC/EAN 13（13mil）
Language
multiple languages
Field of View
42°(H),30°(V)
SUPPORTED BARCODE SYMBOLOGIES
1D：Codabar，Code128，Code32，Code93，Code39，Code11，EAN13，EAN8，GS1 Databar，GS1-128，Interleaved 2 of 5，Matrix 2 of 5，Industry 2 of 5，UPC-A，UPC-E，ISBN，ISSN
2D：Aztec Code，DataMatrix，PDF417，Micro PDF417，QR Code，Micro QR Code
