Specifications
Specifications
PHYSICAL CHARACTERISTICS
Dimension (L*W*H)
90mm*67mm*168mm(L*W*H)
Weight
120g
ENVIRONMENTAL
Temp
-20°- 65°C(operation) ， -30°- 70°C (storage)
Humidity
5 - 90% (operation),5 - 90% (storage)
Shock drop test
1.5m drop onto concrete surface
Ambient light
0-80，000lx
ELECTRICAL
Interface
RS-232/USB HID KEYBOARD/USB VCP
Voltage requirement
DC5V±10%
Current consumption
Max:250mA
OPTICAL CHARACTERISTICS
Photo sensor
CMOS linear sensor
Sensor resolution
1280x800 pixels
Light source
White LED*1
Aim light source
Red Bar LED
SCANNING PERFORMANCE
Decode angle
Pitch angle:±70°
Skew angle:±70°
Tilt angle:±180°
Min resolution
1D：0.101mm/4mil（PCS 0.9）
2D：0.178mm/7mil（PCS 0.9）
Min.PCS value
>20%UPC/EAN 13（13mil）
Language
Multiple languages
Field of View
53°(H),33°(V)
SUPPORTED BARCODE SYMBOLOGIES
1D：UPC-A/UPC-E；EAN-8/EAN-13；Code128；Code39；Code93；Code32；Code11；Codabar；Plessey；MSI；Interleaved 2 of 5；IATA 2 of 5；Matrix 2 of 5；Straight 2 of 5；Pharmacode；RSS-14；RSS-14 Expanded；RSS-14 Limited；Composite Code-A；Composite Code-B；Composite Code-C；
2D： PDF417；Micro PDF417；Data Matrix；QRcode；Micro QR；Aztec；MaxiCode
