Specifications
Specifications
PHYSICAL CHARACTERISTICS
Dimensions
65mm x 61mm x 31mm
Weight
34g
Configurations
Decode
ENVIRONMENTAL
Ambient Light
Fluorescent light 1600 Lux max, direct sun light 80,000 lx max
Operating Temperature
0° to 50°C
Storage Temperature
-5°C to 55°C
Humidity
5 - 95% (operation) 5 - 95% (storage)
Shock drop test
1.2m drop onto concrete surface
ELECTRICAL
Interface
TTL/USB/RS-232/RS-485
Interface connector
0.5-12P FPC
Voltage requirement
DC 5V±5%(USB/TTL/RS232/RS485)
Current consumption
Max:135mA
Min:74mA
OPTICAL CHARACTERISTICS
Photo sensor
CMOS array sensor
Sensor Resolution
640X480 pixels
Light source
Whtie LED*4
SCANNING PERFORMANCE
Decode angle
Tilt angle：±30°
Skew angle：±40°
Pitch angle：±180°
Field of View
68°(H),54°(V)
SUPPORTED BARCODE SYMBOLOGIES
1D : Code 128,Code 39,Code93，EAN-8,EAN-13,UPC-A,UPC-E,ISBN,ISSN
2D：QR
