Specifications
Specifications
PHYSICAL CHARACTERISTICS
Dimensions
65mm x 61mm x 31mm
Weight
32g
Configurations
Decode
ENVIRONMENTAL
Ambient Light
Fluorescent light 1600 Lux max, direct sun light 80,000 lx max
Operating Temperature
0° to 50°C
Storage Temperature
-5°C to 55°C
Humidity
5 - 95% (operation) 5 - 95% (storage)
Shock drop test
1.2m drop onto concrete surface
ELECTRICAL
Interface
TTL/USB/RS-232/RS-485
Voltage requirement
DC 5V±5%(USB/TTL/RS232/RS485)
Current consumption
Max:180mA
Min:100mA
OPTICAL CHARACTERISTICS
Photo sensor
CMOS array sensor
Sensor Resolution
640X480 pixels
Light source
Whtie LED*4
SCANNING PERFORMANCE
Decode angle
Tilt angle：±65°
Skew angle：±60°
Pitch angle：±180°
Field of View
42°(H),30°(V)
SUPPORTED BARCODE SYMBOLOGIES
1D : Codebar，Code128,Code39,Code32,Code93 ,EAN13，EAN8，GS1-Databar，GS1-128（EAN-128），Interleaved 2 of 5，Matrix 2 of 5，Industrial 2 of 5，UPC-A，UPC-E，ISBN，ISSN
2D：PDF417, Data Matrix, QR Code，Micro QR Code，Aztec Code
